Product Description
The GN5/GP5 (natural gas/propane) is the newest model produced for the Val6 series. It incorporates a gas burner into our infrared heater technology as it utilizes a premixed combustion burner that creates a blue flame due to premixing the fuel gas and air in advance. This means virtually silent operation and clean combustion.
Advantages
CLEAN COMBUSTION – The efficiency of our premixed gas combustion system means the GAS VAL6 produces less than 1 ppm of carbon monoxide – 10-20 times less than typical torpedo-style heaters.
QUIET OPERATION – The premixed gas combustion allows VAL6 GN5 and GP5 to minimize operation noise, coming in at about 60dB as compared with a typical forced air heater, at 75dB, or more.
ADJUSTABLE ANGLE – The vertical angle of the radiation disk is adjustable up to 90 degrees.
Specifications
| Heat Output | 144,000 BTU/hr 42.2kW |
| Fuel | GN5 = Natural Gas GP5 = Propane Gas |
| Fuel Consumption | GN5 = 137 CFH, 6.1 lbs/hr
GP5 = 55.8 CFH, 6.6 lbs/hr |
| Power Source | 120V 60 Hz |
| Power Consumption | When igniting: 107W
When burning: 93W |
| Noise Level | 60 dB (A) |
| Dimension (H x W x D) | 35.3 x 31.7 x 30.3 (inch) |
| Weight | 108.1 lbs |
| Safety Devices | Tip over detection, Overheat protection, Auto-restart prevention Fuse |
